Aurora II Integra OPO - Tunable Pulsed Laser System

Manufactured by: Litron Lasers

Quick Overview

Tuning range 400-710nm and 710nm to 2.3µm

An innovative, fully motorised, type II BBO OPO and Nd:YAG pump laser integrated into a single system.

The Aurora II Integra range of type II BBO OPOs has been designed with reliability, stability and ease of use in mind. This allows researchers to concentrate o..

Description

Description

Tuning range 400-710nm and 710nm to 2.3µm

An innovative, fully motorised, type II BBO OPO and Nd:YAG pump laser integrated into a single system.

The Aurora II Integra range of type II BBO OPOs has been designed with reliability, stability and ease of use in mind. This allows researchers to concentrate on their experiments and industrial system integrators the peace of mind that their process will be consistent and robust. With a wide choice of integrated and optimised Nd:YAG pump lasers from 10Hz to 200Hz these are truly flexible systems.

Key Features

    Tuning range 400-710nm and 710nm to 2.3µm
    UV harmonic option for 205-419nm
    Linewidth <3cm-1
    Fully integrated pump laser and OPO
    Motorised OPO tuning with optional closed loop wavelength feedback
    OPO optical compensation and 1064nm variable optical attenuator
    355nm process shutter with energy monitoring as standard
    Full PC control via RS232

Options Include

    Motorised and closed loop automatic tuning of pump laser harmonics
    Auto-stabilisation of pump energy including power supply control
    Automated no gap output tuning from 205nm to 2.3µm
